CR1510

● No-load power consumption < 30mW at 230VAC with typical application circuit

● Supports universal input voltage range (90VAC to 277VAC)

● Isolated design without opto-coupler

● Internal 750V power bipolar junction transistor (BJT)

● Very tight LED current regulation (±5%) across line and load,

   and within primary inductance tolerance (±20%)

● Supports wide range of capacitive loads (from 33μF to 2000μF or higher)

● EZ-EMI® design enhances manufacturability

● Intrinsically low common mode noise

● Adaptively controlled soft start-up enables fast and smooth LED current start-up

● Optimized 64kHz maximum PWM switching frequency

achieves best size and efficiency

● Quasi-resonant operation for highest overall efficiency

● Dynamic base current control to drive internal BJT

● No external compensation components required

● Built-in short circuit protection and output overvoltage protection

● No audible noise over entire operating range
