PS9822-1,-2

产品详情

DESCRIPTION

The PS9822-1 and PS9822-2 are active-low type high-speed photocouplers that use a GaAlAs light-emitting diode on the input side and a photodetector IC that includes a photodiode and a signal processor on the same chip on the output side.
The PS9822-1, -2 are high-speed digital output type photocouplers designed specifically for low circuit current.
The PS9822-2 is suitable for high density applications.

FEATURES

. Supply Voltage
N rank: VCC = 3.3 V
L rank: VCC = 5 V
. Pulse width distortion (⏐tPHL−tPLH⏐ = 200 ns MAX.)
. 40% reduction of mounting area (5-pin SOP × 2)
. High-speed (1 Mbps)
. High isolation voltage (BV = 2 500 Vr.m.s.)
. Open collector output
. Ordering number of tape product : PS9822-1-F3: 1 500 pcs/reel
: PS9822-2-F3: 1 500 pcs/reel
. Pb-Free product

APPLICATIONS

. PoE (Power over Ethernet)
. Measurement equipment
. FA Network
